| **攻丝 | Max tapping | 16mm | 16mm | 16mm | | **钻孔直径 | Maximum Drilling Diameter | 25mm | 25mm | 25mm | | **面铣直径 | Maximum face milling diameter | 63mm | 63mm | 63mm | | 主轴锥度 | Spindle taper | MT3 | MT3 | R8 | | 主轴行程 | Spindle stroke | 50mm | 50mm | 50mm | | 工作台尺寸 | Workbench size | 500×180mm | 500×180mm | 700×180mm | | 工作台行程(X,Y) | Worktable stroke (X,Y) | 320mm×178mm | 285×160mm | 480×160mm | | T型槽尺寸 | T-slot size | 3×12mm | 3×12mm | 3×12mm | | 主轴变速方式 | Spindle speed change | Variable | Variable | Variable | | 主轴转速范围 | Spindle speed range | 50~2500RPM | 100~2500RPM | 100~2500RPM | | 头部左右旋转 | Rotate the head left and right | ±90° | ±90° | ±90° | | 主轴中心至立柱距离 | Distance from spindle center to column | 201mm | 160mm | 160mm | | 主轴端面至工作台距离 | Distance from spindle end face to table | 45~300mm | 370mm | 370mm | | 电机 | motor | 750W | 1.1KW | 1.1KW | | 机床尺寸 | Machine size | ≈870×550×860mm | 750×580×940mm | 950×580×940mm | | 包装尺寸 | Package Size | ≈700×700×840mm | 600×540×910mm | 750×710×930mm | | 毛重 | Gross weight | ≈125kg | 115kg | 130kg | | 净重 | net weight | ≈105kg | 105kg | 115kg |
|
