| 床身回转直径 | Maximum swing | 330mm |
| 中拖板回转直径 | Swing over cross slide | 210mm |
| **顶针距 | Maximum ejector distance | 1000mm |
| 床面长×宽×高 | Bed length×width×height | 1600×182×292mm |
| 主轴中心高 | Spindle center height | 166mm |
| 主轴头部型式 | Spindle head type | D4 |
| 主轴通孔直径 | Spindle bore | 38.5mm |
| 主轴端内孔锥度 | Spindle end bore taper | MT5 |
| 主轴转速级数 | Spindle speed series | 18 steps |
| 主轴转速范围 | Spindle speed range | 65～1810r/min |
| 大拖板纵向行程 | Longitudinal stroke of large carriage | 845mm |
| 中拖板宽度 | Middle pallet width | 120mm |
| 中拖板横向行程 | Transverse travel of middle carriage | 160mm |
| 刀架小拖板宽度 | Width of the small carriage of the knife holder | 76mm |
| 刀架小拖板行程 | Tool holder small carriage travel | 85mm |
| 刀具工位数 | Number of tool stations | 4 |
| **刀具截面尺寸 | Maximum Tool Section Size | 20×20mm |
| 大丝杠外径/螺距 | Large screw diameter/pitch | Φ22mm/3mm |
| 车削公制螺纹 | Turning Metric Threads | 0.4～7.0mm/32 |
| 车削英制螺纹 | Turning inch thread | 4～60T.P.I/36 |
| 光杠外径 | Light rod outer diameter | Φ20mm |
| 中拖板丝杠螺距 | Screw pitch of middle carriage | 2mm |
| 主轴每转纵向进给量 | Screw pitch of middle carriage | 0.053～1.291mm/40 |
| 主轴每转横向进给量 | Spindle traverse feed per revolution | 0.010～0.247mm/40 |
| 尾架套筒直径 | Tailstock sleeve diameter | Φ32mm |
| 尾架套筒行程 | Tailstock sleeve travel | 95mm |
| 尾架套筒锥度 | Tailstock sleeve taper | MT3 |
| 主电机功率 | Main motor power | 1.5KW |
| 净重 | net weight | 494KG |
| 机器尺寸（含底柜） | Machine size (including base cabinet) | 1892×770×1380mm |
| 包装尺寸（含底柜） | Packing size (including base cabinet) | 1860×760×1600mm |
